Nominal Pressure:

16 bar

Display Range:

0.1 litres to 9999 cubic meters

Approval:

Certified and approved by the National Regulator for Compulsory Specifications (NRCS) in accordance with SANS 1529- 1:2006 and the provisions of chapter 5, section 22(1) and 22(2)(a) and (b) of the Legal Metrology Act (Act 9 of 2014).

Mechanical Data:

- Nominal Diameter 15mm 20mm

- Nominal Flow Rate (qn) ±2% mᵌ/h 1.5 2.5

- Minimum Flow Rate (qmin) (Q1) ±5% l/h

- Nominal Working Pressure (Pn) kPa 1600 1600 Pressure loss group of meter P100

- Working Temperature Range °C 0.1°C - 50°C 0.1°C - 50°C N

Dimensions:

- H x L x W: 32cm x 11cm x 17cm

- Weight: 2.5kg

Wall Mounting Specifications:

- Class C, 15mm x 114mm

- Pulse output, non-return valve & strainer inside meter

- External Connections Female BSP & Male BSP

Stop Valve:

- 15mm ball valve

- Plastic ball valve (3 way trickle flow)
