Voltage:

- Rated operating voltage(Un) 220V/380V;

Frequency:

- 50 Hz

Current:

- Basic Current (I) 10A

- Maximum working current - 100A

Plug-in Communication Module options (Smart Meter Only):

- GPRS/GSM Module

Operating Environment:

- Working Temp: -25°C - +75°C

- Storage Temp: –40 to +80 °C

- Humidity - Day = 100% Night = 25%

Current Specification 10(100)A:

- Tripolar bistable latching relay 120A

- Standard class of load switch: UC3(IEC62055-31)

- Maximum switching power of disconnection:

- 27600VAX3

Terminals:

- Terminals layout complies with BS5685/ DIN 43857

- Hole diameter: 9mm; hole depth: 30mm: hole distance: 20mm

- Maximum Cable Cross Section: 35 mm2

Dimensions:

- Extended Cover

L = 300mm

W = 170mm

D = 85mm

Weight:

- +- 1200g
