Voltage:

- Rated operating voltage(Un) 220V;

Frequency:

- 50 Hz

Current:

- Basic Current (I) 5A

- Maximum working current - 60A; 100A

Plug-in Communication Module options (Smart Meter Only):

- GPRS/GSM Module

- PLC Module

Operating Environment:

Working Temp: -25°C - +75°C

Storage Temp: –40 to +80 °C

Humidity: - Day = 100% Night = 25%

RF electromagnetic interference resistance test:

- Standard: IEC 61000-4-3

- With current status: 80MHz to 2GHz 10 V/m

- No current status: 80MHz to 2GHz 30V/m

Terminals:

- Terminals layout complies with BS5685/ DIN 43857

- Main terminal is the pressure-plate type; two screws for a wire.

- Hole diameter: 9mm; hole depth: 30mm: hole distance: 20mm

- Maximum Cable Cross Section: 35 mm2 V

Dimensions:

- Extended Cover:

L = 210mm

W = 135mm

D = 72mm

- Short Cover:

L = 162.2mm

W = 135mm

D = 72mm

Weight:

+- 600g
