Approved meter data:

MID classifications:

Approval:

- Mechanical environment: Class M1

- Electromagnetic environment: Class E2

OIML R 49 designations:

- Accuracy class: 2

- Sensitivity class: U0/D0

- Ambient class: Fulfils OIML R 49 class B and O (building/outdoor)

- Medium temperature, cold water: 0.1...50 °C (T50)

- Meter types Q3 = 160, 250, 400, 630 and 1000 m³/h

- Ambient temperature range: 5...55 °C, condensing humidity (Mounted indoors in utility rooms and outdoors in meter pits –mounting in direct prolonged sunlight must be avoided).

Radio communication:

RE-D (Radio Equipment Directive)

Drinking water approvals:

- KIWA, KTW-BWGL (All parts are suitable for drinking water)

Material:

Wetted parts:

- Meter flow part: Stainless steel, W.no. 1.4408 (316)

- Transducer pocket: PPS

- O-ring/gasket: EPDM

Non-wetted parts

- Flange: Cast iron, EN-GJS-500-7C, black FBE coating

Technical data:

Electrical data:

- Battery: 2 x 3.65 VDC lithium D-cell (replaceable)

- Battery lifetime: Up to 20 years depending on selected data package and ambient installation temperature.

Mechanical data:

- Metrological class: 2

- Protection class: IP68

- Storage temp. empty sensor: -25…60 °C (< 40 °C for a prolonged storage time)

- Impact energy levels IK08 according to IEC62262

- Pressure stage PN16 all sizes

- Connection Split flange, EN 1092-1
