AC Voltage

L1: 85-277 Vrms
L2: 0-277 Vrms
L3: 0-277 Vrms

DC Voltage

42 Vrms
Power: 9-60 Vdc
Measurement: +/-60 Vdc

Current

15 channels
5-6900A max per channel
Isolated inputs

Frequency

50 or 60 Hz

Logging Values

V, A, W, Wh, Hz, VA, VAr, THD, deg

Power Draw

12W max, 2W typical

Environmental

Operating Temperature

-30 to 70 deg C (-22 to 158 F)

Max Altitude

4000m (13,123ft)

Max Humidity

80% up to 31 deg C

Measurement Category

Overvoltage Category III

Location

Open type indoor device

Pollution Degree

2

Data Logger Capacity

Register Count

64 (data storage points)

Granularity
(duration/avg)

1 hour/1 second
1 year/1 minute
10 yrs/15 minute
Device Lifetime/1 Day

Safety and Regulatory

Safety

IEC/UL 61010-1 Ed. 3.0 B:2010

CE

IEC 61000-6-1 Ed. 3.0 B:2016
IEC 61000-6-3 Ed. 2.1 B:2011

FCC

FCC Title 47 CFR Part 15-Subpart B Class B
ICES-003 Information Technology Equipment Class B

Communication

Ethernet

IEEE 802.3 - LAN

User Interface

Compatible Browsers

Recent versions of:

• Google Chrome
• Firefox
• Safari
• Internet Explorer

Enclosure

Material

FRABS

Dimensions

17 x 8 x 4.6cm
(6.7 x 3.15 x 1.81in)

Weight

300g (0.66lbs)
